Glas.C Glass Cutting Table (BQ)
Offering a tilting loading system, cutting and breakout, the Glas.C Glass Cutting Table (BQ) requires limited space and features easy transportation and installation.
Features- Heavy load-bearing table
- Heavy aluminum alloy bridge and wallboard
- Two-stage cutting
- Integral type head
- Welded frame structure
- Roller shaft and heavy-duty bearings
- 3 tilting arms
- Pneumatic tilting
- Air Cushion
- Heavy load-bearing table
- Heavy aluminum alloy bridge and wallboard
- Two-stage cutting
- Integral type head
- Welded frame structure
- Roller shaft and heavy-duty bearings
- 3 tilting arms
- Pneumatic tilting
- Air Cushion
SpecificationsMin Glass Size 39.4 X 59 in. Glass Thickness 3 - 19 mm. (0.12 - 0.75 in.) Working Envelope 98.4 X 78.7 in. - 240.2 X 131.9 in. Cutting Speed 590.6 ft/min. Max Acceleration 14.8 ft/sec. Straight Accuracy ±0.15/2000 Shape Accuracy ±0.1-0.2 Glass Weight 990 - 2205 lbs. Max Cutting Size 110.2 X 165.4in. Min Cutting Size 39.4 X 59 in.
| Min Glass Size | 39.4 X 59 in. |
|---|---|
| Glass Thickness | 3 - 19 mm. (0.12 - 0.75 in.) |
| Working Envelope | 98.4 X 78.7 in. - 240.2 X 131.9 in. |
| Cutting Speed | 590.6 ft/min. Max |
| Acceleration | 14.8 ft/sec. |
| Straight Accuracy | ±0.15/2000 |
| Shape Accuracy | ±0.1-0.2 |
| Glass Weight | 990 - 2205 lbs. |
| Max Cutting Size | 110.2 X 165.4in. |
| Min Cutting Size | 39.4 X 59 in. |
